| UOM | EA | Seal Material | Nitrile |
| Actuation Type | Electrical | Flow Rate | 8, 9.5 GAL/MIN, 30, 36 L/MIN |
| Configuration | Normally Closed, Partially Pressure Compensated | Actuation Type | Electrical |
| Maximum Operating Pressure | 3000 psi | Seal Material | Nitrile |
| Connection Size | n/a | Connection Type | n/a |
| Body Material | n/a | Division | Hydraulic Cartridge Systems Division |
| Division | Hydraulic Systems Division | Flow Direction | Bi-directional |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Minimum Operating Temperature | -30 °F |
| Weight | 0.12 kg | Override Functionality | n/a |
| Cavity Size | C10-2 | Maximum Inlet Pressure Rating | 3000 psi |
| Operation Type | Solenoid Operated | Installation Torque | 30 Nm |
| Coil Nut Tightening Torque | 3 lb-ft | Maximum Operating Temperature | +121 °C |
| Function | Proportional Flow Control/Regulator | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Frequency | 100-400 Hz | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Valve Material | All parts steel. All operating parts hardened steel | Operating Temperature | -34 to +121 °C |
| Wire Mesh Screen Included | No | Variation of Closing Point | N/A |
| Minimum Pressure Differential | N/A psi | Coil Type | 5/8" Super Coil |
| Hysteresis | < 10% | Current | Max: 1.50 @ 12 VDC, 2.33 @ 12 VDC, 0.75 @ 24 VDC, 1.17 @ 24 VDC A |
| Flow Rate | 8, 9.5 Gal/min | Leak Rate | 378 @ 3000 PSI (210 BAR) cm3/min |
| Configuration | Normally Closed, Partially Pressure Compensated | Maximum Flow Rate | 8, 9.5 Gal/min |
| Power Consumption | 18, 28 W | Flow Rate Accuracy | +/- 5% |
| Variation of Opening Point | 17% of Input Signal, 21% of Input Signal | | |
