Graco 247955 | Piston Pump | Pneumatic | 2.5 GPM Maximum Flow Rate | 360 psi Maximum Working Pressure | T1 Model | 1/4 Inch Air Inlet Size | NPT Air Inlet Thread
Availability:
Backordered
Estimated Lead Time: 10 days
Partner Available:Backordered
SKU 247955
POR
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Graco's family of transfer pumps maintain performance in any environment. Transfer pumps are required to feed chemical to your Reactor spray machine or any other equipment requiring fluid transfer. Consider your material viscosities, desired output rate, interior ceiling height of your rig, and available air pressure when choosing your ideal transfer pump.

Features

  • Provide consistent feed pressures and flow rates for dependable results
  • Lower pressure drops with higher viscosity materials at any ambient temperature
  • Designed and manufactured by the worldwide leader in pump technology
  • Longer lasting pump
  • Quick-release bung adapter for easy drum removal without interference from hose connections
  • Stainless steel wetted parts for corrosion-resistance
  • PTFE seals for improved performance and less maintenance

Applications

  • Industrial
Products specifications
Attribute nameAttribute value
UOMEACycles Per Gallon40
Weight18.5 lbPackage OptionsAir Supply & Supply Hose
Maximum Working Pressure360 psiPump Ratio2:1
Fluid Outlet Thread TypeNPTSound Pressure Level88.7 dB(A)
Air Inlet Thread TypeNPTFluid Outlet Thread GenderFemale
Seal MaterialPTFEMaximum Continuous Cycle Rate100 CPM
Sound Power Level96.8 dB(A)Maximum Operating Temperature180 deg F
Fluid Outlet Size1/2 InchAir Inlet Thread GenderFemale
Maximum Air Inlet Pressure180 psiAir Inlet Size1/4 Inch
ModelT1
