24X813

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 24X813

$804.65/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Output Volume	0.305 Cubic Inch
Series	XL	Dispense Outlet Thread Type	NPT
Dispense Outlet Size	0.13 Inch	Suggested Operating Pressure	2500 psi
Maximum Working Pressure	414 bar; 6000 psi	Adjustable	Yes
Maximum NLGI Grade	#2	Inlet Thread Type	NPT
Compatible Material	Grease	Maximum Reset Pressure	1000 psi
Inlet Size	3/8 Inch	Compatible Metering Device	Single Line Parallel
Outlet Size	3/8 Inch	Model	GL-1
Minimum Operating Pressure	1850 psi	Minimum Output Volume	0.035 Cubic Inch
Outlet Thread Type	NPT	Maximum Operating Pressure	6000 psi
Cycle Indicator	Visual
