25C919

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 25C919

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Flow Rate	20 GPM
Meter Technology	Oval Gear	Calibration Type	Factory Calibrated
Maximum Working Pressure	102 bar; 1500 psi	Outlet Size	7/8 Inch
Unit of Measure	Quart;Pint;Liter;Gallon	IP Rating	69K
Extension Type	Rigid	Meter Pressure Loss	85 psi at 12 GPM
Inlet Thread Type	NPT	Outlet Thread Type	ORB
Trigger Protection Type	Lock Off Button	Maximum Storage Temperature	185 deg F
Meter Accuracy	±0.5 %	Metering Gun Weight	3.1 lb
Outlet Thread Gender	Female	Display Type	Electronic
Inlet Thread Gender	Female	Minimum Flow Rate	0.25 gpm
Recommended Environment	Indoor/Outdoor	Inlet Size	3/4 Inch
Minimum Operating Temperature	-22 deg F	Overall Width	3.5 Inch
Overall Height	5.25 Inch	Nozzle Type	Manual
Maximum Recorded Dispense	19999	Maximum Operating Temperature	180 °F
Overall Length	13 Inch	Approvals	CE
Model	EM20	Compatible Material	Petroleum-Based Oil;Synthetic-Based Oil;Antifreeze
Trigger Lock	Locking
