*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

25C930

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 25C930

Products specifications

Attribute name	Attribute value
UOM	EA	Meter Technology	Oval Gear
Maximum Flow Rate	20 GPM	Calibration Type	Factory Calibrated
Maximum Working Pressure	102 bar; 1500 psi	Trigger Protection Type	Lock Off Button
Outlet Thread Gender	Female	Meter Accuracy	±0.5 %
Metering Gun Weight	3.1 lb	Unit of Measure	Quart;Pint;Liter;Gallon
IP Rating	69K	Display Type	Electronic
Maximum Storage Temperature	185 deg F	Extension Type	Flexible
Minimum Operating Temperature	-22 deg F	Outlet Thread Type	ORB
Trigger Lock	Locking	Compatible Material	Petroleum-Based Oil;Synthetic-Based Oil;Antifreeze
Overall Height	5.25 Inch	Model	EM20
Inlet Thread Type	BSPP	Minimum Flow Rate	0.25 gpm
Inlet Size	3/4 Inch	Recommended Environment	Indoor/Outdoor
Inlet Thread Gender	Female	Outlet Size	7/8 Inch
Meter Pressure Loss	85 psi at 12 GPM	Overall Length	13 Inch
Nozzle Type	Manual	Maximum Operating Temperature	180 °F
Approvals	CE	Overall Width	3.5 Inch
Maximum Recorded Dispense	19999
