25M416

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 25M416

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Flow Rate	18 GPM
Meter Technology	Oval Gear	Maximum Working Pressure	103.4 bar; 1500 psi
Outlet Thread Type	Straight Thread O-Ring Boss	Inlet Thread Gender	Female
Recommended Environment	Indoor	Minimum Flow Rate	0.25 gpm
Model	SDM18	Inlet Size	3/4 Inch
Trigger Lock	Non-Locking	Overall Height	5.75 Inch
Overall Width	3.75 Inch	Maximum Recorded Dispense	9999
Maximum Operating Temperature	158 °F	Overall Length	13 Inch
Nozzle Type	Manual	Metering Gun Weight	5.3 lb
Minimum Operating Temperature	4 deg F	Compatible Material	Oil;Antifreeze;ATF;Gear Oil
Trigger Protection Type	Guard	Extension Type	Rigid
Maximum Storage Temperature	158 deg F	Inlet Thread Type	NPT
Display Type	Electronic	Meter Accuracy	±0.5 %
Dispense Type	Manual	Unit of Measure	Quart;Pint;Gallon;Liter
Outlet Thread Gender	Female
