25M417

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 25M417

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Working Pressure	103.4 bar; 1500 psi
Meter Technology	Oval Gear	Maximum Flow Rate	18 GPM
Outlet Thread Gender	Female	Trigger Protection Type	Guard
Meter Accuracy	±0.5 %	Display Type	Electronic
Unit of Measure	Quart;Pint;Gallon;Liter	Dispense Type	Manual
Overall Height	5.75 Inch	Trigger Lock	Non-Locking
Extension Type	Flexible	Inlet Thread Type	NPT
Recommended Environment	Indoor	Model	SDM18
Compatible Material	Oil;Antifreeze;ATF;Gear Oil	Outlet Thread Type	Straight Thread O-Ring Boss
Minimum Flow Rate	0.25 gpm	Overall Width	3.75 Inch
Inlet Size	3/4 Inch	Maximum Recorded Dispense	9999
Inlet Thread Gender	Female	Metering Gun Weight	5.3 lb
Nozzle Type	Manual	Maximum Storage Temperature	158 deg F
Overall Length	13 Inch	Maximum Operating Temperature	158 °F
Minimum Operating Temperature	4 deg F
