*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

25N771

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 25N771

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Working Pressure	103.4 bar; 1500 psi
Meter Technology	Oval Gear	Maximum Flow Rate	8 GPM
Recommended Environment	Indoor	Trigger Lock	Locking
Minimum Flow Rate	0.25 gpm	Compatible Material	Oil;Antifreeze;ATF;Gear Oil
Outlet Thread Type	Straight Thread O-Ring Boss	Overall Width	3.75 Inch
Maximum Recorded Dispense	9999	Inlet Thread Gender	Female
Maximum Storage Temperature	158 deg F	Metering Gun Weight	5.3 lb
Dispense Type	Preset	Overall Length	13 Inch
Maximum Operating Temperature	158 °F	Minimum Operating Temperature	4 deg F
Outlet Thread Gender	Female	Unit of Measure	Quart;Pint;Gallon;Liter
Display Type	Electronic	Trigger Protection Type	Guard
Extension Type	Bare	Overall Height	5.75 Inch
Meter Accuracy	±0.5 %	Model	SD
