26C354

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 26C354

Products specifications

Attribute name	Attribute value
UOM	EA	Meter Technology	Oval Gear
Maximum Flow Rate	8 GPM	Maximum Working Pressure	103.4 bar; 1500 psi
Compatible Material	Oil;ATF	Dispense Type	Preset
Trigger Protection Type	Guard	Maximum Storage Temperature	158 deg F
Metering Gun Weight	5.3 lb	Display Type	Electronic
Inlet Thread Type	NPT	Meter Accuracy	±0.5 %
Inlet Size	1/2 Inch	Unit of Measure	Quart;Pint;Gallon;Liter
Outlet Thread Gender	Female	Outlet Thread Type	Straight Thread O-Ring Boss
Nozzle Type	Oil Automatic Quick-Close	Extension Type	Flexible
Inlet Thread Gender	Female	Overall Height	5.75 Inch
Overall Width	3.75 Inch	Recommended Environment	Indoor
Minimum Flow Rate	0.25 gpm	Maximum Recorded Dispense	9999
Minimum Operating Temperature	4 deg F	Maximum Operating Temperature	158 °F
Overall Length	13 Inch	Trigger Lock	Locking
Model	SDP8
