26C355

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 26C355

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Working Pressure	103.4 bar; 1500 psi
Meter Technology	Oval Gear	Maximum Flow Rate	8 GPM
Minimum Flow Rate	0.25 gpm	Compatible Material	Antifreeze;Oil;ATF
Overall Width	3.75 Inch	Trigger Lock	Locking
Nozzle Type	Oil Automatic Quick-Close	Maximum Recorded Dispense	9999
Inlet Thread Gender	Female	Outlet Thread Type	Straight Thread O-Ring Boss
Recommended Environment	Indoor	Overall Length	13 Inch
Dispense Type	Preset	Maximum Operating Temperature	158 °F
Metering Gun Weight	5.3 lb	Model	SDP8
Minimum Operating Temperature	4 deg F	Maximum Storage Temperature	158 deg F
Outlet Thread Gender	Female	Trigger Protection Type	Guard
Display Type	Electronic	Unit of Measure	Quart;Pint;Gallon;Liter
Meter Accuracy	±0.5 %	Overall Height	5.75 Inch
Inlet Size	1/2 Inch	Inlet Thread Type	NPT
Extension Type	Flexible
