*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

27KAIW21EVX

Availability:	Backordered
Partner Available:	Backordered

SKU 27KAIW21EVX

$593.18/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Materials of Construction	Stainless Steel AISI 316L
Length	56.5 mm	For Fluid Type	Breathing Air
Application	Food & Beverages	Compatible Fitting	Series 27 Plug
Flow Rate	2400 lpm (Air)	Technology	Pneumatics
Shape	Straight	Maximum Outside Diameter	27 mm
Valve Included	Yes	Operation Type	Sleeve
Function	Single Shut-Off	Connection Size	G 1/2 Inch
Maximum Flow Rate	2400 lpm (Air)	Standard	RoHS
Flow Diameter	10 mm (Nominal)	Valve Type	High Flow Valve
Coupling Half	Coupler	Plating Type	Without Surface Treatment
Minimum Operating Temperature	-15 °C	Version	Single Shut-Off
Sleeve Material	Brass	Hex Size	24 mm
Seal Material	FKM	Interchange Type	European Profile
Maximum Operating Temperature	392 °F	Product Series	Series 27
