| UOM | EA | Seal Material | Nitrile |
| Flow Rate | 16 GAL/MIN, 60 L/MIN | Actuation Type | Electrical, Manual |
| Configuration | Normally Closed, Pressure Compensated | Actuation Type | Electrical |
| Maximum Operating Pressure | 3000 psi | Seal Material | Nitrile |
| Connection Size | n/a | Connection Type | n/a |
| Body Material | n/a | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Minimum Operating Temperature | -34 °C | Override Functionality | n/a |
| Operation Type | Solenoid Operated | Installation Torque | 30 Nm |
| Coil Nut Tightening Torque | 3 lb-ft | Flow Rate | 60 L/min |
| Maximum Flow Rate | 16 Gal/min | Maximum Operating Temperature | +121 °C |
| Function | Proportional Flow Control/Regulator | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Frequency | 100-400 Hz | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Valve Material | All parts steel. All operating parts hardened steel | Maximum Inlet Pressure Rating | 210 bar |
| Configuration | Normally Closed, Pressure Compensated | Flow Direction | Inlet port 3, Bypass port 2, Regulated port 4 |
| Coil Type | 5/8" Super Coil | Weight | 0.31 lb |
| Power Consumption | 18, 28 W | Minimum Pressure Differential | 13.8, 20.7 bar |
| Current | 1.50 @ 12 VDC, 2.33 @ 12 VDC, 0.75 @ 24 VDC, 1.17 @ 24 VDC A | Leak Rate | 780 @ 3000 PSI (210 BAR) cm3/min |
| Hysteresis | 7% | Cavity Size | 4C |
| Flow Rate Accuracy | +/- 50% of Input Signal | Variation of Opening Point | 17% Nominal Amperage, 21% Nominal Amperage |
| Maximum Regulated Flow Rate | 7, 8 Gal/min | | |
