| UOM | EA | Flow Direction | 2-1 De-energized, 3-1 Energized |
| Configuration | Normally Closed, Normally Open, Selector | Maximum Inlet Pressure Rating | 3000 PSI, 210 BAR |
| Actuation Type | Electrical, Manual | Seal Material | Fluorocarbon |
| Flow Rate | 11, 12, 13 GAL/MIN, 41.6, 45.4, 49.2 L/MIN | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Division | Hydraulic Systems Division | Weight | 0.59 kg |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Response Time | 90-100 ms |
| Valve Material | All parts steel. All operating parts hardened steel | Body Material | n/a |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Maximum Flow Rate | 13 Gal/min |
| Mounting Type | Screw in cartridge valve | Leak Rate | 82 @ 3000 PSI (210 BAR) cm3/min |
| Minimum Operating Temperature | -26 °C | Configuration | Normally Closed, Normally Open, Selector |
| Actuation Type | Electrical, Manual | Flow Direction | 2-1 De-energized, 3-1 Energized |
| Flow Rate | 41.6, 45.4, 49.2 L/min | Input Voltage | 85% of rated voltage at 72°F (20°C) min |
| Cavity Size | C16-3 | Coil Type | 1" DS Coil |
| Maximum Operating Temperature | +204 °C | Installation Torque | 40 lb-ft |
| Maximum Inlet Pressure Rating | 3000 psi | Override Functionality | Push Type |
| Function | 3-Way | Operating Temperature | -15 to +400 °F |
| Seal Material | Fluorocarbon | Maximum Operating Pressure | 210 bar |
| Operation Type | Solenoid operated, Manually operated | Coil Nut Tightening Torque | 4.1 Nm |
