| UOM | EA | Seal Material | Nitrile |
| Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR | Actuation Type | Electrical, Manual |
| Configuration | Normally Closed, Normally Open, Selector | Flow Direction | 2-1 De-energized, 3-1 Energized |
| Flow Rate | 2, 3 GAL/MIN, 7.5, 11.3 L/MIN | Seal Material | Nitrile |
| Body Material | n/a | Maximum Operating Pressure | 5000 psi |
| Division | Hydraulic Systems Division | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Function | 3-Way | Minimum Operating Temperature | -34 °C |
| Weight | 0.13 kg | Maximum Inlet Pressure Rating | 5000 psi |
| Cavity Size | C08-3 | Installation Torque | 43-49 Nm |
| Actuation Type | Electrical, Manual | Maximum Operating Temperature | +250 °F |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Operation Type | Solenoid operated, Manually operated | Valve Material | All parts steel. All operating parts hardened steel |
| Operating Temperature | -34 to +121 °C | Mounting Type | Screw in cartridge valve |
| Coil Type | 1/2" Super Coil | Configuration | Normally Closed, Normally Open, Selector |
| Input Voltage | 85% of rated voltage at 72°F (20°C) min | Response Time | 50 ms |
| Override Functionality | Push and Twist | Coil Nut Tightening Torque | 5-7 lb-ft |
| Flow Direction | 2-1 De-energized, 3-1 Energized | Flow Rate | 7.5, 11.3 L/min |
| Leak Rate | 160 @ 5000 PSI (350 BAR) cm3/min | Maximum Flow Rate | 11.3 L/min |
