4.00CBB4MA3U18AC10.00

Manufacturer: Parker Hannifin

Availability:	Backordered
Partner Available:	Backordered

SKU 4.00CBB4MA3U18AC10.00

$556.42/each

Products specifications

Attribute name	Attribute value
UOM	EA	Material	Clear Anodized Aluminum Alloy
Series	4MA	Style	Tie Rod, NFPA
Port Size	1/2 Inch	Stroke Length	10 Inch
Lube Specification	Non Lube Design	Corrosion Resistant	Yes
Filtration Required	40 micron	Piston Material	Aluminum
Max. Temperature Range	165 °F	Mounting Style Code	BB
Mounting Style	MP1	Rod End Style	Male, Intermediate
Seal Type	Lipseal	Max. Pressure	250 psig
Filter Media	Filtered Air	Magnetic Ring	Yes
Rod Material	Case Hardened, Chrome-Plated Carbon Steel	Bumpers	w/o Bumpers
Rod Diameter	1 Inch	Rod Thread Type	UNF
Rod End Thread	7/8-14	End Type	Single Rod
Min. Temperature Range	-10 °F	Seal Material	Nitrile
Port Type	NPTF	Piston No.	1
Bore Size	4 Inch	Cushions	Cushioned, Both Ends
