654512

Manufacturer: Graco

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 654512

Products specifications

Attribute name	Attribute value
UOM	EA	Material	Polypropylene
Type	Pneumatic	Connection Type	End Flange ANSI/DIN
Weight	57 lb	Series	15120
Maximum Flow Rate	120 GPM	Ball Material	PTFE
Air Exhaust Port Thread Gender	Female	Diaphragm Compatible Material	PTFE
Fluid Outlet Size	1-1/2 Inch	Fluid Inlet Thread Gender	Female
Fluid Inlet Size	1-1/2 Inch	Air Exhaust Port Size	1 Inch
Diaphragm Material	PTFE Overmold	Minimum Storage Temperature	32 deg F
Air Inlet Thread Gender	Female	Manifold Configuration	End Port
Maximum Air Consumption	85 SCFM	Minimum Operating Temperature	32 deg F
Air Inlet Thread Type	NPT	Model	Husky
Air Exhaust Port Thread Type	NPT	Maximum Cycle Rate	183 CPM
Maximum Operating Temperature	150 deg F	Air Inlet Size	1/2 Inch
Fluid Outlet Thread Gender	Female	Maximum Solid Size	0.25 Inch
