654532

Manufacturer: Graco

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 654532

Products specifications

Attribute name	Attribute value
UOM	EA	Material	Polypropylene
Type	Pneumatic	Connection Type	Center Flange ANSI/DIN
Weight	57 lb	Series	15120
Maximum Flow Rate	120 GPM	Ball Material	PTFE
Seat Material	PVDF (Kynar)	Air Exhaust Port Thread Gender	Female
Fluid Outlet Size	1-1/2 Inch	Air Exhaust Port Size	1 Inch
Fluid Inlet Size	1-1/2 Inch	Fluid Inlet Thread Gender	Female
Minimum Storage Temperature	32 deg F	Air Inlet Thread Gender	Female
Air Inlet Thread Type	NPT	Minimum Operating Temperature	32 deg F
Manifold Configuration	Center Port	Maximum Air Consumption	85 SCFM
Air Inlet Size	1/2 Inch	Air Exhaust Port Thread Type	NPT
Maximum Operating Temperature	150 deg F	Model	Husky
Maximum Solid Size	0.25 Inch	Maximum Cycle Rate	183 CPM
Fluid Outlet Thread Gender	Female	Diaphragm Material	PTFE/EPDM 2-Piece
Diaphragm Compatible Material	PTFE
