7262-06-06-NWO-FG

Manufacturer: Brennan

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 7262-06-06-NWO-FG

Products specifications

Attribute name	Attribute value
UOM	EA	Thread Size 2	3/8-19
Series	7262-NWO-FG	Centerline Length	29.47 MM
Shape	90 Degree Angle	Type	Elbow
Centerline Length M	34.26 MM	Material	Steel
Hex C 1	17.5 MM	Plating	CR3
Maximum Dynamic Pressure	5,100 psi	Thread Size 1	9/16-18
Thread Specification 1	SAE J514	Hex Body	19 MM
Raw Material Type	Steel Forging	O-Ring/Seal Material	NBR
Thread Drill 1	7.5 MM	Thread Type	Male SAE Adjustable O- Ring Boss
Thread Type 2	Male BSPP with 60 Degree Seat	Thread Specification 2	60 Degree Seat Swivel Connection
Thread Drill 2	9.5 MM
