7303-08-08-06-FG

Manufacturer: Brennan

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 7303-08-08-06-FG

Products specifications

Attribute name	Attribute value
UOM	EA	Style	Tee Adapter
Series	7303-FG	Thread Size 2	3/4-16
Connection Type	MJ-FJ-FBSPP	Type	Tee
Max. Dynamic Pressure	5800 psi	Weight	0.313 LB
Standard	Prop-65 Warning	Material	Steel
Thread Type 3	Female BSPP (G)	Plating	CR3
Thread Type 1	Male JIC SAE 37 Degree Flare	Thread Type 2	Female JIC Swivel 37 Deg Flare
Thread Specification 1	SAE J514	Thread Size 3	3/8-19
Raw Material Type	Steel Forging	Thread Specification 2	SAE J514
Thread Specification 3	ISO 1179, ISO 8434-6, BS 5200	Thread Size 1	3/4-16
