797ST Series
*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.
Parker’s GlobalCore 797ST hose provides 6,000 psi (35 MPa) constant working pressure in all sizes. ½ bend radius of SAE spiral hose. Flex impulse tested providing a hose superior in both performance and service life. Meets ISO 18752 performance specification.
Read More...| Action | SKU | Availability | Partner Available | Price | UOM | Inner Diameter | Mating Fitting Series | Working Pressure | Material | ISO 18752 Performance | Inner Diameter Inch/mm | Parker Division | Parker Group | Mating End Fitting Series | Series | Trade Name | Inch/Metric | Distinct Properties | Hose Pressure Range | Inner Diameter | Operating Temperature | Hose Category | Material | Minimum Bend Radius | Working Pressure Range | Specification | Working Pressure | Application |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 797ST-4-BX | Backordered | Backordered | $9.91/foot | FT | 0.25 Inch | 43 | 6,000 psi (42 MPa) | Rubber | AC | Inch | Hose Products | Fluid Connector | 43 | 797ST | GlobalCore | Inch | Super Tough Cover Constant Pressure 6000 PSI | High | 0.25 Inch | -40°F to +212°F (-40°C to +100°C) | Hydraulic Industry Standard | Rubber | 2 Inch | > 5000 PSI (345 bar) | ISO 18752 | 6,000 psi (42 MPa) | Hydraulic | |
| 797ST-4-RL | Backordered | Backordered | $8.01/foot | FT | 0.25 Inch | 43 | 6,000 psi (42 MPa) | Rubber | AC | Inch | Hose Products | Fluid Connector | 43 | 797ST | GlobalCore | Inch | Super Tough Cover Constant Pressure 6000 PSI | High | 0.25 Inch | -40°F to +212°F (-40°C to +100°C) | Hydraulic Industry Standard | Rubber | 2 Inch | > 5000 PSI (345 bar) | ISO 18752 | 6,000 psi (42 MPa) | Hydraulic | |
| 797ST-6-BX | Backordered | Backordered | $27.56/foot | FT | 0.375 Inch | 43 | 6,000 psi (42 MPa) | Rubber | CC | Inch | Hose Products | Fluid Connector | 43 | 797ST | GlobalCore | Inch | Super Tough Cover Constant Pressure 6000 PSI | High | 0.375 Inch | -40°F to +212°F (-40°C to +100°C) | Hydraulic Industry Standard | Rubber | 2 1/2 Inch | > 5000 PSI (345 bar) | ISO 18752 | 6,000 psi (42 MPa) | Hydraulic | |
| 797ST-6-RL | Backordered | Backordered | $22.27/foot | FT | 0.375 Inch | 43 | 6,000 psi (42 MPa) | Rubber | CC | Inch | Hose Products | Fluid Connector | 43 | 797ST | GlobalCore | Inch | Super Tough Cover Constant Pressure 6000 PSI | High | 0.375 Inch | -40°F to +212°F (-40°C to +100°C) | Hydraulic Industry Standard | Rubber | 2 1/2 Inch | > 5000 PSI (345 bar) | ISO 18752 | 6,000 psi (42 MPa) | Hydraulic | |
| 797ST-8-RL | Backordered | Backordered | $35.39/foot | FT | 0.5 Inch | 43 | 6,000 psi (42 MPa) | Rubber | DC | Inch | Hose Products | Fluid Connector | 43 | 797ST | GlobalCore | Inch | Super Tough Cover Constant Pressure 6000 PSI | High | 0.5 Inch | -40°F to +257°F (-40°C to +125°C) | Hydraulic Industry Standard | Rubber | 4 Inch | > 5000 PSI (345 bar) | ISO 18752 | 6,000 psi (42 MPa) | Hydraulic |
