8399-R-22-22-22-FG

Manufacturer: Brennan

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 8399-R-22-22-22-FG

Products specifications

Attribute name	Attribute value
UOM	EA	Series	8399-FG
Material	Steel	Thread Size 2	M22 x 1.5
Connection Type	MK-FKS-MK	Style	Tee Adapter
Thread Type 4	ISO 261	Type	Tee
Weight	0.419 LB	Hex Size 1	27 MM
Standard	Prop-65 Warning	Thread Drill 3	12 MM
Thread Specification 3	Metric Thread With 30D Flare	Plating	CR3
Thread Type 1	Male Komatsu	Thread Type 2	Female Komatsu Swivel
Thread Specification 2	Metric Thread With 30d Flare	Thread Specification 1	Metric Thread With 30D Flare
Thread Size 1	M22 x 1.5	Thread Size 3	M22 x 1.5
Body Hex	22 MM	Raw Material Type	Steel Forging
Thread Drill 1	12 MM	Thread Type 3	Male Komatsu
Thread Drill 2	12 MM
