9244-24-24

Manufacturer: Brennan

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 9244-24-24

Products specifications

Attribute name	Attribute value
UOM	EA	Type	Elbow
Material	Steel	Series	9244
Thread Size 2	1-1/2-11	Shape	90 Degree Angle
Maximum Dynamic Pressure	1,500 psi	Thread Specification 1	ISO 1179, ISO 8434-6, BS 5200
Thread Type 2	Female BSPP Swivel	Thread Size 1	1-1/2-11
Thread Type	Female BSPP Swivel	Thread Specification 2	ISO 1179, ISO 8434-6, BS 5200
Hex C 1	55 MM	Hex C 2	55 MM
Raw Material Type	Bent Tube	Plating	CR3
