9621-10-10-NWO-FG

Manufacturer: Brennan

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 9621-10-10-NWO-FG

Products specifications

Attribute name	Attribute value
UOM	EA	Material	Steel
Type	Elbow	Shape	90 Degree Angle
Series	9621-NWO-FG-ORR	Thread Size 2	5/8-14
Thread Type 2	Male BSPP Adjustable ORR	O-Ring/Seal Material	NBR
Thread Specification 1	60 DEG Seat Swivel Connection	Raw Material Type	Steel Forging
Thread Type	Male BSPP with 60 Degree Seat	Maximum Dynamic Pressure	2,900 psi
Plating	CR3	Thread Specification 2	O-Ring and Retaining Ring; for ISO 1179 Port; ISO 8434-6; BS 5200
Thread Size 1	5/8-14
