Brass 45° Flare Fittings - 166FSV-4-4

Name: Brass 45° Flare Fittings - 166FSV-4-4
SKU: 166FSV-4-4

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Availability:

Backordered

SKU 166FSV-4-4

$10.50

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 1 Type	Flare
Connection 1 Thread Size	7/16-20 inch	Connection 1 Tube Outside Diameter	1/4 inch
Connection 3 Tube Outside Diameter	NA	Connection 3 Type	NA
Connection 2 Thread Size	1/4 inch	Connection 3 Thread Size	NA
Connection 2 Tube Outside Diameter	NA	Connection 2 Type	NPT Swivel Nut
Shape	90° Swivel Elbow	Product Style	Flare to Female Flare Swivel
Brand	PARKER	Division	Fluid System Connectors Division
Body Material	Brass	Division	Fluid System Connectors Division
Technology	Fluid & Gas Handling	O-Ring Material	Fluorocarbon
Maximum Operating Temperature	121 °C	Minimum Operating Temperature	-65 °F
Application	Adapters, Fuels, Natural Gas, Propane, Refrigerant Lines	Dimensional Weight	0.27594424460431655 lb
Specifications Met	SAE J512, SAE J513	Maximum Operating Pressure	2800 psi
Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon	Nut Material	Brass
Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
