Brass Inverted Flare Fittings - 245IFHD-6-4

Name: Brass Inverted Flare Fittings - 245IFHD-6-4
SKU: 245IFHD-6-4

Parker's economical inverted flare fittings offer a metal-to-metal seal that is internal to the fitting for tighter tube bends. Meets functional requirements of SAE J512

Availability:

Backordered

SKU 245IFHD-6-4

$29.03

Products specifications

Attribute name	Attribute value
UOM	EA	Shape	Branch Tee
Connection 2 Tube O.D. (inch)	na	Connection 1 Tube O.D. (inch)	3/8
Connection 2 Style	Male Pipe	Connection 2 Thread Size (inch)	1/4
Connection 1 Style	Inverted Flare	Style	Flare to Pipe
Division	Fluid System Connectors Division	Maximum Operating Pressure	1000 psi
Body Material	Brass	Maximum Operating Temperature	121 °C
Minimum Operating Temperature	-65 °F	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared	Specifications Met	SAE J512
Application	Pumps, Brake Lines	Nut Material	Brass, Zinc Chromate Steel
