252IFHD-6-4 - Brass Inverted Flare Fittings

Name: 252IFHD-6-4 - Brass Inverted Flare Fittings
SKU: 252IFHD-6-4
Price: 25.80 USD
Availability: InStock

Parker's economical inverted flare fittings offer a metal-to-metal seal that is internal to the fitting for tighter tube bends. Meets functional requirements of SAE J512

Availability:

12 in stock

Springfield, MO	11
Springfield, MO	1

Partner Available:

15 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 252IFHD-6-4

$25.80/each

Qty:

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Shape	Branch Tee
Connection 2 Tube O.D. (inch)	na	Connection 1 Tube O.D. (inch)	3/8
Connection 2 Style	Male Pipe	Connection 2 Thread Size (inch)	1/4
Connection 1 Style	Inverted Flare	Style	Flare to Female Pipe
Maximum Operating Pressure	1000 psi	Body Material	Brass
Maximum Operating Temperature	250 °F	Minimum Operating Temperature	-53 °C
Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon	Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
Specifications Met	SAE J512	Nut Material	Brass, Zinc Chromate Steel
