41IFS-8 - Brass Inverted Flare Fittings

Parker's economical inverted flare fittings offer a metal-to-metal seal that is internal to the fitting for tighter tube bends. Meets functional requirements of SAE J512

Availability:	Backordered Estimated Lead Time: 5 days
Partner Available:	1 Limited Stock

SKU 41IFS-8

$6.10/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 2 Style	na
Connection 2 Thread Size (inch)	na	Connection 2 Tube O.D. (inch)	na
Connection 1 Tube O.D. (inch)	1/2	Connection 1 Style	Inverted Flare
Style	Flare	Shape	Zinc Nut
Body Material	Brass	Maximum Operating Temperature	121 °C
Minimum Operating Temperature	-53 °C	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared	Maximum Operating Pressure	52 bar
Specifications Met	SAE J512	Nut Material	Brass, Zinc Chromate Steel
