CD1030

Manufacturer: Graco

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU CD1030

$4,636.00/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Weight	66 lb
Maximum Working Pressure	3500 psi	Maximum Input Amperage	10 A
Fluid Outlet Size	3/8 NPT and/or 1/4 NPT Inch	Number of Pump Elements	1
Lower Type	Shovel	Fluid Outlet Thread Type	Tapered Pipe Thread (NPT)
Low Level Switch Rating	24 VDC	Maximum NLGI Grade	2
Overall Width	11.5 Inch	IP Rating	IP69K
Control Options	Integrated electrical motor controller	Maximum Operating Temperature	149 deg F
Maximum Fluid Output Pressure	3500 PSI	Component Technology	Brushless Electric Motor;Shovel-loading pump tube
Maximum Continuous Cycle Rate	64 CPM	Voltage	24 VDC
Power Connection Type	Deutsch DT04-12PB Housing	Overall Height	39.0 Inch
Motor Type	Brushless DC	Sound Power Level	<80 dB(A)
Maximum Voltage	30 VDC	Overall Depth	13.9 Inch
Approvals	CE;RCM	Minimum Operating Temperature	-40 deg F
Maximum Cycle Rate	64 CPM	Minimum Voltage	18 VDC
Power Rating	0.25 HP	Throat Seal Type	Hythane 181
Fluid Outlet Thread Gender	Female	Maximum cST Grade	NLGI #2 Grease cST
Low Level Carry Current	0.02 A
