CM2AAN - CHECK SANDWICH VALVE - CM SERIES

Parker’s CM series check valves is an integral, full flow check valve.

Availability:	Backordered Estimated Lead Time: 27 days
Partner Available:	1 Limited Stock

SKU CM2AAN

$295.68/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Size	NFPA D03; CETOP 3; NG6
Mounting Type	Subplate	Maximum Flow Rate	20 GPM
Maximum Operating Pressure	5000 PSI	Maximum Operating Temperature	+140
Weight	1.7	Port Connection	A Port Check
Minimum Operating Temperature	-4	Maximum Flow Rate	20
Product Style	Sandwich Check Valve	Media	Oil
Cracking Pressure	5	Body Material	Steel
Size	NFPA D03	Actuation Type	Hydraulic Pressure
Seal Material	Nitrile	Mounting Type	Subplate
Maximum Operating Pressure	5000
