Colorflow Check Valve – C Series - 9C2000S

Name: Colorflow Check Valve – C Series - 9C2000S
SKU: 9C2000S

Parkers Colorflow C series hydraulic check valves offer superior construction and versatility with a variety of materials, sizes and ports. These one-way check valves are used in hydraulic and pneumatic applications in the mobile & industrial markets.

Availability:

Backordered

SKU 9C2000S

$504.00

Products specifications

Attribute name	Attribute value
UOM	EA	Body Material	Steel
Maximum Operating Pressure	5000	Connection Type	BSPP
Cracking Pressure (psi)	5	Minimum Operating Temperature	-40
Maximum Operating Temperature	250	Actuation Type	Mechnical
Maximum Flow Rate (gpm)	70	Connection Size	1 1/4"
Function	Check	Media	Hydraulic Oil
Configuration	In-line	Flow Direction	Free Flow in one Direction
Mounting Type	In-line	Seal Material	N/A
Flow Direction	Free Flow in one direction shut-off in reverse	Maximum Operating Temperature	205 °C
Maximum Flow Rate	265 L/min	Configuration	Inline
Brand	Colorflow	Cracking Pressure	5 psi
Maximum Operating Pressure	3000 psi	Division	Hydraulic Valve Systems Division
Flow Rate	n/a	Seal Material	Nitrile
Function	Mechanical	Mounting Type	Inline
Connection Size	1-1/4 inch	Minimum Operating Temperature	-40 °F
Body Material	Steel	Media	Hydraulic
Connection Type	BSPP	Actuation Type	Mechanical
