*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

DT-500-FSMS-5 - Compact, Hydraulic In Line Check Valves - DT Series

Parker's in line check valves are one way flow control devices used primarily in hydraulic systems to eliminate potential damage caused by fluid back pressure.

Availability:	Backordered Estimated Lead Time: 12 days
Partner Available:	3 in stock

SKU DT-500-FSMS-5

$72.40/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Working Pressure (psi)	5000
Cracking Pressure (psi)	5	Outlet Port Size (inch)	5000
Outlet Port Connection Type	Male Seal-Lok	Inlet Port Size (inch)	13/16 - 16 UN
Inlet Port Connection Type	Female Seal-Lok	Minimum Operating Temperature	-40 °F
Body Material	Steel	Maximum Operating Temperature	250 °F
Maximum Operating Pressure	5000 psi	Configuration	n/a
Mounting Type	Threaded	Actuation Type	Mechanical
Maximum Flow Rate	n/a	Flow Direction	n/a
Body Size	1/2 inch	Seat Type	Metal Seal
Seal Material	Metal & Elastomeric	Connection Size	13/16 - 16 UN
Connection Type	Female Seal-Lok inlet Male Seal-Lok outlet

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories (PDF)

Literature and Reference Materials
