D1FVE02CC0VKW3

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 80 days
Partner Available:	Backordered

SKU D1FVE02CC0VKW3

$2,796.00/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Function	3-way
Port Connection	NG06 / CETOP 03	Maximum Flow Rate	10 lpm
Material	Cast Iron	Operation Type	Direct
For Fluid Type	Water Glycol	Actuation Type	Solenoid
Product Series	Proportional DC Valve	Mounting Option	Subplate
Solenoid Connection	Connector As Per EN 175301-803	Seal Material	FPM
Minimum Operating Temperature	-20 °C	Solenoid Option	12 V / 2.2 A
Mounting Position	Unrestricted	Spool Position	Operated In Position A Or B
Maximum Operating Temperature	60 °C
