D2601-E06-E06-02-SS

Manufacturer: Brennan

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU D2601-E06-E06-02-SS

Products specifications

Attribute name	Attribute value
UOM	EA	Material	Stainless Steel
Type	Tee	Connection Type	MBT-MBT-MP
Weight	0.066 LB	Series	D2601
Style	DIN Fitting	Hex Size 1	12 MM
Thread Size 2	M10 x 1.0	Standard	Prop-65 Warning
Max. Dynamic Pressure	100 Bar	Connection Specification 1	DIN 2353, ISO 8434-1
Raw Material Type	Stainless Steel Forging	Thread Size 3	1/8-27
End Type 2	DIN Metric Tube Compression	Connection Specification 3	ANSI B1.20.1
Hex Size 2	12 MM	End Type 1	DIN Metric Tube Compression
End Type 3	Male NPT	Connection Specification 2	DIN 2353, ISO 8434-1
Thread ID	4.5 MM	Thread Size 1	M10 x 1.0
Tube Size 2	6 MM	Body Hex	9 MM
Tube Size 1	6 MM
