D7601-S14-S14-08-SS

Manufacturer: Brennan

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU D7601-S14-S14-08-SS

Products specifications

Attribute name	Attribute value
Standard	Prop-65 Warning	Max. Dynamic Pressure	400 Bar
Hex Size 1	27 MM	Connection Type	MBT-MBT-MBSPT
Style	DIN Fitting	Thread Size 2	M22 x 1.5
Series	D7601	Material	Stainless Steel
Type	Tee	Weight	0.592 LB
Connection Specification 1	DIN 2353, ISO 8434-1	Thread ID	10 MM
End Type 2	DIN Metric Tube Compression	End Type 1	DIN Metric Tube Compression
End Type 3	Male BSPT (R)	Thread Size 3	1/2-14
Raw Material Type	Stainless Steel Forging	Tube Size 2	14 MM
Hex Size 2	27 MM	Connection Specification 3	ISO 7-1, DIN EN 10226-1
Tube Size 1	14 MM	Thread Size 1	M22 x 1.5
Connection Specification 2	DIN 2353, ISO 8434-1	Body Hex	19 MM
