Direct Acting Relief Valves - RD102S09

Name: Direct Acting Relief Valves - RD102S09
SKU: RD102S09

Parker’s direct acting relief valves are available in several cavity sizes and are designed for continuous duty applications with pressures up to 420 bar (6000 psi) and flows up to 200 lpm (53 gpm).

Availability:

Backordered

SKU RD102S09

$46.33

Products specifications

Attribute name	Attribute value
UOM	EA	Adjustment Mechanism	Screw
Seal Material	D-Ring (Standard)	Flow Rate	10 GAL/MIN, 38 L/MIN
Maximum Inlet Pressure Rating	3600 PSI, 250 BAR	Pressure Control Range	100-900 PSI, 7-62 BAR
Body Material	n/a	Division	Hydraulic Systems Division
Maximum Kinematic Viscosity	45-2000 SSU (6 to 420 cSt)	Minimum Operating Temperature	-35 °F
Maximum Operating Temperature	+200 °F	Maximum Operating Pressure	3600 psi
Weight	0.5 lb	Function	Direct Acting
Configuration	Pressure Relief	Actuation Type	Pressure Sensing
Operation Type	Automatic	Adjustment Mechanism	Screw
Wire Mesh Screen Included	n/a	Cavity Size	C10-2
Flow Rate	10 Gal/min	Seal Material	D-Ring (Standard)
Maximum Flow Rate	38 L/min	Filter Efficiency Rating	ISO 4406 18/16/13, SAE Class 4
For Fluid Type	Mineral-based or synthetic hydraulic fluids	Valve Material	All parts steel. All operating parts hardened steel
Mounting Type	Screw in cartridge valve	Operating Temperature	-35 to +200 °F
Maximum Tank Pressure	210 bar	Maximum Inlet Pressure Rating	250 bar
Installation Torque	37-41 lb-ft	Leak Rate	5 @ 75% Crack Pressure drops/min
Reseat Pressure	85% of pressure setting	Pressure Control Range	6.9-62 bar
Maximum Pressure Setting	62 bar	Standard Setting Pressure	31 bar
Pressure Control Sensitivity	7.2 per turn bar
