23790-6-6 - Field Attachable Fittings for PTFE Hose - 90 Series

Parker's 90 Series fittings are used with 919/919B PTFE hoses from Parflex division.

Availability:	Backordered Estimated Lead Time: 14 days
Partner Available:	1 Limited Stock

SKU 23790-6-6

$35.25/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Hose I.D. (inch)	0.313"
Length (inch)	1.96"	Connection 2 Size	9/16"-18
Product Style	Female JIC 37° - Swivel - 45° Elbow - Short Drop	Body Material	Steel
Maximum Operating Pressure	207 bar	Specifications Met	N/A
Coating	Chromium 6 Free-plated	Configuration	Hose to Port
For Fluid Type	Oil	Connection 1 Type	Hose
Tube Outside Diameter	n/a	Connection 1 Size	5/16 inch Hose I.D.
Hex Size	11/16 inch (see drawing legend H)	Industry	Food & Beverage
Fitting Length	50 mm	Connection 2 Type	Female
Connection 2 Size	9/16"-18 inch Thread	Hex Size 1	11/16 inch (see drawing legend J)
Shape	Elbow 45° Short Drop	Dimensional Weight	0.0264 lb
Connection Length	44 mm
