FS1600S - Flow Control, Subplate Mounted Valve – FS Series

Parker’s FS series flow control valve offers superior construction and high versatility due to its variety of materials, sizes and port styles. It can be used in both the mobile and industrial markets.

Availability:	Backordered Estimated Lead Time: 98 days
Partner Available:	Backordered

SKU FS1600S

$7,492.00/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Flow Rate	40 GPM
Maximum Operating Pressure	3000 PSI	Mounting Type	Subplate
Size	1"	Maximum Operating Temperature	n/a
Body Material	Steel	Function	Flow Control
Configuration	n/a	Connection Size	1 inch
Maximum Operating Pressure	3000 psi	Cracking Pressure	5 psi
Needle Type	Standard	Weight	2.31 kg
Maximum Flow Rate	40 Gal/min	Minimum Operating Temperature	n/a
Actuation Type	Manual	Connection Type	Subplate mounting
Flow Rate	n/a	Seal Material	Nitrile

Product resources

Literature and Reference Materials

CATALOGUE - Throttle Check Valve Series FS (Europe and Asia) (PDF)
