FG-K26280-KW - Fuel Drip Bunker Samplers

Parker bunker samplers are designed to provide a representative sample of the entire fuel delivery. Manufactured from stainless steel.

Availability:	Backordered Estimated Lead Time: 7 days
Partner Available:	Backordered

SKU FG-K26280-KW

$0.24/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Product Style	IMO MARPOL Aprooved Fuel Sample Label
Quantity per Box	1000	Cycle Time	n/a
Accuracy	n/a	Sensing Range	n/a
Operating Pressure	580	Electrical Requirements	n/a
Industry	Transportation	Sensor Connection	n/a
Size	515 to 840 x 31.5 x 95 to 401 mm (Height x Width x Diameter)	Features	Simple and effective continuous fuel sampling for the entire delivery as ISO 13739<br/>ASTM D 4057: 2000 Standard practice for manual sampling of petroleum and petroleum products
Flow Rate	Needle valve to control drip rate	Options	Wide range of line diameters: 50 mm (2") up to 300 mm (12") in 25 mm (1")
Weight	3 to 12	Wetted Material	Stainless steel, PTFE, non-asbestos grade Y gasket (aramid/glass fibres and nitrile rubber)
Signal Output	n/a	For Fluid Type	Mineral and synthetic fluids: Lubricant oils, hydraulic oils, distillate fuels, water-based fluids and bio-based fuels
Sensing Method	n/a	Accessories Included	Sample containers, anti-tamper locks, bottle seals and labels available separately
Communication Interface	n/a	Ingress Protection Rating	N/A
Connection Type	Multiple line diameter versions from 50 mm to 350 mm
