Fuel Filter Water Separator – Racor Spin-on Series - 490R30

Name: Fuel Filter Water Separator – Racor Spin-on Series - 490R30
SKU: 490R30

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.

Availability:

Backordered

SKU 490R30

$390.90

Products specifications

Attribute name	Attribute value
UOM	EA	Location	North America and EMEA regions
Micron Rating	98% @ 30 Micron	Mounting	Bracket Included
Bowl Type	Standard, Clear Engineering Plastic	Part Type	Filter Assembly
Bowl Material	Clear Engineering Plastic	Heater Power Rating	No Heater
Port Size	3/8"-18 NPTF (SAE J476)	Product Series	Diesel Spin-on 400
Integral Primer Pump Included	Button Priming Pump (Diesel)	Flow Rate	90 gph (341 lph)
Division	Engine Mobile Original Equipment Division	Brand	Racor
Operating Temperature	-40 to 121 °C	Product Type	Diesel Spin-on FF/WS
Head Material	Aluminium Alloy	Number of Ports	2 Inlet / 2 Outlet
Filter Element Type	30 Micron Aquabloc Spin-on	Accessories Included	See Product Support Tab
Maximum Operating Pressure	207.0 kPa	For Fluid Type	Diesel
Maximum Fluid Temperature	88.0 °C	Width	114.0 mm
Depth	4.8 inch	Height	300.0 mm
Weight	1.4 kg	Compatible Element	R90S = "2" Micron<br/>R90T = 10 Micron<br/>R90P = 30 Micron
Clean Pressure Drop	6.5 kPa

Product resources

Literature and Reference Materials, Selector Guides

Racor--400 Diesel Spin-on--RSL0366 (PDF)

Literature and Reference Materials
