*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

G15B77

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU G15B77

Graco’s Merkur bellows piston pumps provide low maintenance with no seals exposed to the atmosphere. These pumps are designed to eliminate conventional throat seals, providing high reliability for moisture-sensitive materials.

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Working Pressure	1500 psi
Maximum Flow Rate	2.4 GPM	Series	Bellows
Pressure Type	High Pressure	Convertible	Non-Convertible
Fluid Outlet Size	3/4 Inch	Pump Ratio	15:1
Power Source	Air	Motor Type	Pneumatic
Pump Type	Pneumatic Piston	Model	Merkur
Fluid Inlet Thread Type	NPT	Gun Included	Yes
Fluid Inlet Size	1 Inch	Gun Type	Air-Assisted
Number of Guns	1	Fluid Outlet Thread Type	NPT
Maximum Hose Length	25 ft	Gun Model	G15
Mount Type	Wall	Outlet Paint Filter	60 Mesh Stainless Steel Screen
Frame Configuration	Wall
