H1-63-BSPP - General Purpose, ISO 7241-B, Hydraulic Quick Couplings - 60 Series

Parker's general purpose quick couplers and nipples are versatile for use across a spectrum of applications where fluid, gas or steam lines require fast and easy connection and disconnection.

Availability:	Backordered Estimated Lead Time: 19 days
Partner Available:	Backordered

SKU H1-63-BSPP

$72.96/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Body Material	Steel
Maximum Operating Pressure	5000	Application	General Purpose
Coupling Half	Male Nipple	Connection Thread Size (inch)	1/8 - 27
Body Size (inch)	1/8	Connection Type	Female BSPP
Seal Material	Nitrile	Valve Material	Steel
Valve Type	Poppet	Flow Rate	3 L/min
Vacuum Pressure Rating	-0.9 bar	Hex Size	0.56 inch
Maximum Operating Temperature	250 °F	Specifications Met	ISO 7241-1, series B
Body Material	Steel	Minimum Operating Temperature	-40 °F
Plating Type	Zinc with clear trivalent chromate
