10356-12-12 - Global Fittings - 56 Series - Inch

Name: 10356-12-12 - Global Fittings - 56 Series - Inch
SKU: 10356-12-12
Price: 46.97 USD
Availability: InStock

The Global 56 Series replaces the 55/58 Series. It is shorter, more compact, and is 20% lighter than comparable fittings.

Availability:

3 in stock

Springfield, MO

Partner Available:

4 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 10356-12-12

$46.97/each

Qty:

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Materials of Construction	Steel
Hose I.D. (inch)	0.75"	Product Style	Male JIC 37° - Rigid - Straight
Length (inch)	3.07"	Connection 2 Size	1-1/16"-12
Body Material	Steel	Shape	Straight
Coating	Chromium 6 Free-plated	Hex Size 1	n/a
Configuration	Hose to Port	Connection 1 Type	Hose
Tube Outside Diameter	n/a	Industry	Industrial Manufacturing Equipment
Hex Size	1-1/8 inch (see drawing legend H)	Hex Size 2	n/a
For Fluid Type	Air (Pneumatic Media)	Maximum Operating Pressure	5000 psi (Dependent on hose)
Fitting Length	78 mm (see drawing legend A)	Shipping Weight	0.181 kg
Connection 1 Size	19.05 mm Hose I.D.	Connection 2 Size	1-1/16"-12 inch Thread
Connection 2 Type	JIC 37°	Connection Length	1-3/4 inch Cut-off allowance
Dimensional Weight	0.0793 lb
