GULLY WASHER® PVC Medium Duty Lay Flat Water Discharge Hose, Series 7542
*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.
Parker's Series 7542 Gully Washer PVC Medium Duty Lay Flat Water Discharge Hose is lightweight and rolls up flat for easy handling, storage and transportation. The distinctive red cover is easy to identify, flame resistant for operator safety, and resistant to abrasion and weathering for maximum performance.
Markets:
• Agriculture
• Construction
• General Industrial
• Surface Mining
Features/Benefits:
• Tube: Red nitrile/PVC for economical service to 140°F.
• Reinforcement: Multiple textile plies for strength and durability.
• Cover: Red PVC for resistance to abrasion, cuts, gouging, scuffs and weathering.
• Lengths: Available in 300-foot continuous lengths for maximum versatility in application and efficient inventory management.
Applications:
- media
• Mild chemicals
• Slurries
• Water
- usage
• Drainage systems
• Irrigation
• Pumps
Industry Standards:
• MSHA
Safety/Technical:
• Design Factor: 3:1
Warnings:
• Working pressures are at +68°F (+20°C). Higher temperatures reduce the available working pressure.
• Couplings attached with bands or clamps may reduce the working pressure of the hose assembly to less than the maximum rated working pressure of the hose. Refer to NAHAD Industrial Hose Assembly Guidelines.
| Action | SKU | Availability | Partner Available | Price | UOM | Hose I.D. (inch) | Minimum Operating Temperature | Media | Maximum Operating Temperature | Cover Color | Cover Material | Minimum Bend Radius | Weight | Inside Diameter | Specifications Met | Outside Diameter | Maximum Operating Pressure | Hose Inner Tube Material | Hose Reinforcement Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7542-1501 | Backordered | 68 in stock | $3.29/foot | FT | 1-1/2 | 14 °F | Water | 140 °F | Red | PVC | n/a | 0.34 kg/m | 38.1 mm | MSHA | 1.7 inch | 6.9 to 19.3 bar | Red | 3 Plies of Textile | |
| 7542-2001 | Backordered | 679 in stock | $4.69/foot | FT | 2 | 14 °F | Water | 60 °C | Red | PVC | n/a | 0.30 lb/ft | 2 inch | MSHA | 55 mm | 100 to 150 psi | Nitrile/PVC | 3 Plies of Textile | |
| 7542-2501 | Backordered | Backordered | $5.64/foot | FT | 2-1/2 | -10 °C | Water | 140 °F | Red | PVC | n/a | 0.55 kg/m | 63.5 mm | MSHA | 2.7 inch | 6.9 to 19.3 bar | Nitrile/PVC | 3 Plies of Textile | |
| 7542-3001 | Backordered | 736 in stock | $8.09/foot | FT | 3 | 14 °F | Water | 140 °F | Red | PVC | n/a | 0.46 lb/ft | 3 inch | MSHA | 80.8 mm | 6.9 to 19.3 bar | Red | 3 Plies of Textile | |
| 7542-4001 | Backordered | 491 in stock | $10.54/foot | FT | 4 | 14 °F | Water | 140 °F | Red | PVC | n/a | 0.66 lb/ft | 101.6 mm | MSHA | 106.8 mm | 0.7 to 1.0 MPa | Nitrile/PVC | 3 Plies of Textile | |
| 7542-6001 | Backordered | 208 in stock | $20.26/foot | FT | 6 | -10 °C | Water | 60 °C | Red | PVC | n/a | 1.52 kg/m | 6 inch | MSHA | 6.2 inch | 100 to 150 psi | Nitrile/PVC | 3 Plies of Textile |
