7181-251 - Heavy Duty Heater Hose, Series 7181

Heavy Duty Heater Hose is designed for use in heater and radiator systems in vehicles and industrial equipment in applications to 257°F and 65 psi, Series 7181

Availability:	Backordered Estimated Lead Time: 12 days
Partner Available:	1581 in stock

SKU 7181-251

$1.24/foot

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	FT	Hose I.D. (inch)	1/4
Maximum Working Pressure (psi)	65	Standard Pack Qty (ft)	700
Minimum Operating Temperature	-40 °C	Inside Diameter	1/4 inch
Cover Material	Ethylene Propylene Diene Monomer (EPDM)	Cover Color	Black
Minimum Bend Radius	63.5 mm	Outside Diameter	0.530 inch
Hose Reinforcement Material	2 Plies of Textile	Package Type	Reel
Compatible Fitting	n/a	Hose Inner Tube Material	Black
Maximum Operating Temperature	257 °F	Media	Coolants
Weight	0.10 lb/ft	Specifications Met	SAE J20R3EC, Class D2
Maximum Operating Pressure	4.5 bar
