HO-252-4FP - High Pressure, High Flow, Steel Quick Couplings with Sleeve Lock - HO Series

Parker's high pressure and high flow quick couplers are ideal for use with high pressure hydraulic applications where fluid lines require fast and easy connection and disconnection while providing maximum flow and low pressure drop.

Availability:	Backordered Estimated Lead Time: 12 days
Partner Available:	26 in stock

SKU HO-252-4FP

$40.04/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Connection Type	Female NPTF
Coupling Half	Male Nipple	Maximum Operating Pressure	15000.0
Connection Thread Size	1/4 - 18	Valve Type	Unvalved
Maximum Operating Temperature	250.0 °F	Minimum Operating Temperature	-40.0 °F
Flow Rate	3.0 Gal/min	Hex Size	0.81 inch
Body Material	Steel	Plating Type	Electroless nickel
Body Size	1/4 inch

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories (PDF)

Literature and Reference Materials
