787ST-20 - Hydraulic Constant Working Pressure Hose 5000 PSI - GlobalCore 787 Hose

Part of the GlobalCore family of robust hydraulic hoses. Parker’s 787 hose delivers 5000 PSI constant working pressure in a lightweight and easy to bend product.

Availability:	Backordered Estimated Lead Time: 36 days
Partner Available:	1295 in stock

SKU 787ST-20

$117.53/foot

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	FT	Hose I.D. (size)	-20
Hose Cover Type	SuperTough Cover	Minimum Operating Temperature	-40 °C
Inside Diameter	1-1/4 inch	Size	-20
Cover Material	Synthetic Rubber	Maximum Operating Temperature	257 °F
Media	Petroleum Hydraulic Fluids	Compatible Fitting	77 Series
Minimum Bend Radius	210 mm	Hose Inner Tube Material	Proprietary Synthetic Rubber Compound
Weight	1.95 lb/ft	Outside Diameter	44.9 mm
Specifications Met	ISO 18752, Type DC	Maximum Operating Pressure	350 bar
Hose Reinforcement Material	4 or 6 Spirals of Steel Wire Compact
