80AT210BBPGY32H - Low Pressure Spin-On Filters 12AT/50AT Series

Our rebranded Spin-On Low Pressure Filter Series are cost effective yet uncompromising in performance and quality. Max allowable operating pressure of 150 PSI/10.3 Bar and capable of flows up to 50 GPM/190 LPM depending on viscosity.

Availability:	Backordered Estimated Lead Time: 28 days
Partner Available:	Backordered

SKU 80AT210BBPGY32H

$334.93/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Options	Inlet & Outlet, both sides (all ports drilled & tapped)
Filter Element	10 micron microglass	Bypass Valve (psi)	25 psid bypass
Port Connection Type	2" SAE Code 61 Flange / 1-1/2" NPT ports	Seal Material	Nitrile
Flow Rate (gpm)	80	Indicator Type	Sold separately
Maximum Operating Temperature	225	Indicator Pressure Setting	1.4
Indicator Type	Sold separately	Options	Inlet & Outlet, both sides (all ports drilled & tapped)
Bypass Valve Pressure Rating	1.7 bar	Flow Rate	80
Mounting Type	Inline	Port Type	2" SAE Code 61 Flange / 1-1/2" NPT ports
Compatible Element	929445	Seal Material	Nitrile
Weight	5.89	For Fluid Type	Suitable for use with mineral and vegetable oils, and some synthetic oils. For other fluids, please e-mail Technical Support at HFF.technical@support.parker.com or call 800-253-1258.
Filter Element Type	Canister

Product resources

Literature and Reference Materials
