Picture of Modular, High Flow, Hydraulic In Line Check Valves - CV Series - CV-750-MFMF-5

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Modular, High Flow, Hydraulic In Line Check Valves - CV Series - CV-750-MFMF-5

Parker's, in line check valves are one way flow control devices used primarily in hydraulic systems to eliminate potential damage caused by fluid back pressure.
Availability:
Backordered
SKU CV-750-MFMF-5
$194.80
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
UOMEAOutlet Port Size (inch)1 1/16 - 12 UN
Inlet Port Connection TypeMale JIC 37 degreeCracking Pressure (psi)5
Body Size (inch)3/4Outlet Port Connection TypeMale JIC 37 degree
Inlet Port Size (inch)1 1/16 - 12 UNConnection Size1-1/16"-12 UN inch
Mounting TypeThreadedMaximum Operating Temperature-40 °F
Maximum Flow Raten/aConfigurationn/a
Minimum Operating Temperature250 °FMaximum Operating Pressure3000 psi
Seal MaterialMetalFlow Directionn/a
Connection TypeMale Flare JIC to Male Flare JICBody MaterialSteel
Actuation TypeMechanicalSeat TypeMetal Seal
DivisionQuick Coupling Division
