P1A-S025MS-0200

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 106 days
Partner Available:	Backordered

SKU P1A-S025MS-0200

$189.93/each

Bypass upcharge for backordered quantity. Check this box if you prefer to backorder out of stock quantities from Hyspeco for this item, then click Add To Cart.

Products specifications

Attribute name	Attribute value
UOM	EA	Stroke Length	200 mm
Filtration Required	40 micron	Material	Stainless Steel
Style	Round Body	Series	P1A
Port Size	G1/8	Lubrication	Prelubricated
Rod Diameter	10 mm	Minimum Temperature Range	-4 °F
Bore Size	25 mm	Retraction Force @ 87 PSI	55.53 lbs
End Cap Material	Anodized Aluminum	Rod Material	Stainless Steel
Cushions	Cushioned, Adjustable Both Ends	Maximum Temperature Range	176 °F
Bumpers	w/o Bumpers	Maximum Pressure	145 psig
Magnetic Piston	Yes	Rod End Thread	M10X1.25
Seal Material	Fluorocarbon	Cylinder Type	Double Acting
Extension Force @ 87 PSI	66.1 lbs
