Picture of 309P-8-4N - Plastic Barbed Fittings, Parker Par-Barbs

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

309P-8-4N - Plastic Barbed Fittings, Parker Par-Barbs

Parker's Par-Barb fttings are specially engineered with a four-barb design that generates maximum gripping and sealing power when combined with a hose clamp.
Availability:
15 in stock
Wichita, KS15
Partner Available:Backordered
Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.
SKU 309P-8-4N
$3.85/each
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
UOMEAColorWhite
Product StyleFemale Pipe to Male PipeConnection 1 Size1/2"
Connection 1 TypeMale PipeConnection 2 Size1/4"
Connection 2 TypeFemale PipeConnection 2 Thread Size1/4"
Connection 2 Hose I.D. (inch)n/aShapeReducer Bushing
Body MaterialNylon,WhiteConfigurationPipe to Pipe
Connection 3 SizeN/AConnection 3 TypeN/A
Connection 1 Thread Size1/2"Connection 1 Hose I.D. (inch)n/a
ColorWhiteMinimum Operating Temperature-40 °C
Connection 1 TypeMale NPTConnection 2 TypeFemale NPT
MediaWaterConfigurationPipe to Pipe
Maximum Operating Temperature93 °CBody MaterialNylon
Specifications MetNSF 51ShapeReducer Bushing
For Fluid TypeOther Compatible FluidsCompatible TubeVinyl
Connection 1 Size1/2Connection 2 Size1/4
Connection 3 SizeN/AConnection 3 TypeN/A
Vacuum Pressure Rating-29Maximum Operating Pressure125 psi
Dimensional Weight0.5755 lb
